Every number, every system, laid out clearly. No surprises. This is exactly what you get.
| Exterior length | 22'10" / 6.96m | Mercedes-Benz Sprinter 170" AWD |
| Exterior width | 8'4" / 2.54m | Standard width, fits most parking spaces |
| Exterior height | 9'6" / 2.90m | Standard components, fixed roof |
| Interior height | 6'2" / 1.93m | Full standing room for those up to 6'2" |
| Interior length | 14'3" / 4.34m | Usable living space aft of bulkhead |
| Gross vehicle weight | 8,150 lbs / 3,697 kg | GVWR dry weight, no CDL required |
| Make & model | Mercedes-Benz Sprinter 170" AWD | High-roof, 170" wheelbase, all-wheel drive standard |
| Engine | 2.0L 4-Cylinder Turbo Diesel (High Output) | 211 horsepower / 332 lb-ft torque |
| Transmission | 9G-TRONIC | 9-speed automatic transmission |
| Drive | 4-MATIC All-Wheel Drive | Full time all-wheel drive, fully automatic, variable torque |
| Fuel capacity | 45 gal / 170L | Upgraded high-capacity fuel tank standard |
| Model year | 2025 or 2026 | Dependent on allocation — current builds on 2025 chassis |
| System | EcoFlow Power Kits Gen 2 | Fully integrated 48V power system — battery, inverter, solar, and alternator charging in one platform |
| Battery | 10 kWh LFP / 800Ah equivalent | EcoFlow LFP Smart Batteries — lithium iron phosphate, heated, modular, 48V nominal |
| Power hub | EcoFlow 5 kVA Power Hub | Central management unit — combines MPPT controller, inverter/charger, and alternator input in a single module |
| Inverter output | 5,000W pure sine / 10,000W peak | Continuous output — runs induction cooktop, appliances, and all loads simultaneously |
| Solar input | 780W / 3,600W capable | Built-in MPPT charge controller — expandable up to 3,600W as needed |
| Alternator charging | Up to 1,000W | Integrated DC-DC charging via Power Hub — recharges while driving without a separate unit |
| Shore power | 30A / 120V hookup | Standard US campsite connection, inlet on driver's side |
| AC outlets | 6 × 110V | Kitchen (×2), workspace (×2), bedroom (×2) |
| USB outlets | 8 × USB-A/C | Distributed throughout — bedside, workspace, kitchen |
| Monitoring | 7" Touchscreen + EcoFlow App | Real-time battery, solar, load, and system health monitoring from your phone or the built-in display |
| Cooktop | 2-zone induction | Max 3500W combined — requires inverter, no propane on cooktop |
| Refrigerator | NovaKool R4500 — 4.3 cu ft / 122L | Built-in freezer compartment (0.6 cu ft / 17L) |
| Sink | Brushed stainless, oversized | Deep enough for a stock pot |
| Freshwater tank | 37 gal / 140L | Stainless steel holding tank, undermounted. Upgradable to 72 gal / 273L. |
| Wastewater tank | 37 gal / 140L | Stainless steel tank, vented, with waste drain connection |
| Water filtration | Guzzle Stealth Flex 5 | 5 micron carbon filter, 12V ultraviolet light, dedicated faucet |
| Countertop surfaces | Sealed butcher block | Easy to clean, repair, and refinish |
| Microwave | LG 1000W microwave oven | Standard, mounted in lower galley |
| Storage | 9 lower drawers / 3 upper cabinets | Various size drawers offer abundant storage, includes 1-gallon trash compartment |
| Heating | Truma Combi heater | Diesel-fuelled, draws from vehicle tank, 2kW, whisper-quiet |
| Air conditioning | Nomadic X3 48V AC | 12,000 BTU, thermostat controlled with remote |
| Insulation | Rockwool ComfortBatt | R30, 2" insulation layer |
| Fresh air | Dual fresh air vents | Forced air, infinite speed control, located at each chair |
| Exhaust | Forced air exhaust vent | Infinite speed control, located between galley and bath |
| Conversion warranty | 2 years | All workmanship, electrical, cabinetry, plumbing |
| Vehicle warranty | 3 years / 36,000 miles | Mercedes-Benz factory warranty. 5 years / 50,000 mile drivetrain. |
| Support | Lifetime phone + email | Reach the team who built your van — not a call centre |
| Remote support | On-call support 24/7 | Have your vehicle serviced at one of our partner shops in the lower-48 states |
| Post-delivery visit | Included | 30-day walkthrough with your builder — in person or remote |
The Cosy Road is built to order. Lead time is currently 24 weeks from deposit. We'll walk you through every step — from chassis selection to delivery day. Reserve one of our limited build slots now.
Specifications are subject to change without notice as we continually refine the build. All weights, dimensions, and performance figures are nominal. Final configuration confirmed in writing before production commences. Images and placeholders shown are representative only.
